10.1 Inch Industrial Touch Monitor
Products Features
• 7mm front bezel
• High-precision aluminum alloy die casting
• Independent research and development of industrial-grade display driver board
• Non-touch / capacitive touch / resistive touch screen for option
• 12-24V wide voltage power supply operation
• HDMI / VGA / DVI multi-signal automatic identification input
• Flexible installation types: panel mount, desktop, embedded, VESA-75/100.
| Screen size | 10.1 inch |
| Model | MDITM-101-M5 |
| Resolution | 1280*800 |
| Proportion | 16:10 widescreen |
| Gray-scale response time | 5ms |
| Panel Type Industrial | Control A+ style TFT |
| Point distance | 0.264mm |
| Contrast | 800:1 |
| Backlight type | LED, life span ≥50000h |
| Display color | 16.7M |
| Visual angle | 160/160 (178° full view angle customizable) |
| Brightness | 400cd/m2 (high brightness customizable) |
| Touch-type | Resistive / capacitive / mouse control |
| Number of touches | ≥ 50 million times |
| Power Supply | 4A External Power Adapter |
| Power Performance | 100-240V, 50-60HZ |
| Input voltage | 12-24V |
| Anti-static | contact 4KV-air 8KV (can be customized ≥16KV) |
| Power | ≤48W |
| Anti-vibration | GB2423 standard |
| Anti-interference | EMC|EMI anti-electromagnetic interference |
| Dust & Water proof | Front panel IP65 dustproof and waterproof |
| Housing Material | Black/Silver, Aluminum Alloy |
| Installation method | Embedded, desktop, Wall / VESA 75 &100 / Panel mount, open frame |
| Ambient temperature | <80%, non-condensable |
| Working temperature | -10°C～60°C (-30°C～80°C customizable) |
| Language menu | Chinese, English, German, French, Korean, Spanish, Italian, Russian, etc. |
| Signal Interface | DVI, HDMI, VGA |
| Power connector | DC with plug (optional DC terminal block) |
| Touch interface | USB |
| Other interfaces | Audio input and output |
